Unifloor, subfloor preparation systems

Acoustic underlay with super low heat resistance
Acoustic underlay with super low heat resistance
Acoustic underlay with super low heat resistance
Acoustic underlay with super low heat resistance

Heat-Foil

  • Impact Sound
  • Walking sound
  • Thermal resistance
  • Fire classes
  • Stability
  • Generally applicable over floor heating / cooling
  • Excellent transference of heat (TOG 0,14)
  • Impact sound reduction 21 dB ΔLw (laminate and engineered)
  • Minimal thickness, only 1.2 mm
  • Optimal oppression against water vapour
  • Self-adhesive overlap

Acoustic underlay with super low heat resistance

Description

Heat-Foil® has been designed especially for application over floor heating and floor cooling systems. Because of a minimal thickness of just 1,2 mm and a density of 150 kg/ m³, Heat-Foil® will simply transmit the warmth to the floor surface (TOG 0,14). Heat-Foil® is made out of a Polyethylene foil (200 micron) with a self adhesive overlap, combined with a most stable Polyethylene layer of foam.

Heat-Foil® is used in combination with various types of floating finished floor coverings, such as click laminate, engineered wood flooring, click LVT, etc. When used over floor cooling systems a guarding systems against the transmission of water vapour needs to be present.

Heat-Foil® combined with Heat-Pak® is the most ideal choice over floor heating and floor cooling for glue down of ALL resilient finished floor coverings, such as sheet vinyl, lino, cork, rubber, LVT and carpet.

Combined with click laminate Heat-Foil® shows an impact sound reduction of 21 dB ΔLw, measured according to ENISO 10140-3: 2010.
